Kit buying instructions for Asia

Purchase the microcontroller board

Please order either a Stellaris Launchpad (EK-LM4F120XL) or a Tiva Launchpad (EK-TM4C123GXL) from one of the distributors listed below or one of the distributors listed on the Worldwide page. All the projects we will develop in these course will run on both these microcontroller boards. The boards may or may not be available at the regional distributors listed below.

Extra electronic parts

element14 in APAC shopping cart

All parts prices are listed in Singaporean Dollars. Make sure to select your correct region for accurate pricing.

Quantity

Description

Manufacturer

Manufacturer Part

Farnell order code

Unit cost

Cost

1

Solderless breadboard + wires

Twin Industries

TW-E41-1020

2213347

$22.66

$22.66

2

Green LED 1.8V 2mA 5mm

VISHAY

TLLG5401

1045509

$0.26

$0.52

2

Red LED 1.8V 2mA 5mm

Multicomp

HLMP4700

1249814

$0.18

$0.35

2

Yellow LED 1.8V 2mA 5mm

VISHAY

TLLY5401

1045510

$0.22

$0.44

6

Carbon 1/4W resistor, 5%, 470

PANASONIC

ERG12SJ471

2324473

$0.20

$1.20

1

Carbon 1/4W resistor, 5%, 1.0k

PANASONIC

ERG12SJ102

2324439

$0.20

$0.20

3

Carbon 1/4W resistor, 5%, 1.5k

PANASONIC

ERG12SJ152

2324448

$0.20

$0.60

3

Carbon 1/4W resistor, 5%, 12k

PANASONIC

ERG12SJ123

2324445

$0.20

$0.60

4

Carbon 1/4W resistor, 5%, 10k

PANASONIC

ERG12SJ103

2324440

$0.20

$0.80

4

B3F push button switch

OMRON

B3F-4000

1436525

$0.27

$1.09

1

Stereo Jack 3pin 3.5mm

MULTICOMP

SPC24110

2112339

$0.62

$0.62

1

Slide Potentiometers 15mm

BOURNS

PTA6043-2015DPB103

1688411

$2.32

$2.32











Total

$31.41


You can order the extra electronic parts for this class either from the element14 in APAC shopping cart above, the Worldwide page, or from one of the local distributors listed below.

Please make sure to order the following:
  • 1 Solderless breadboard (400+ holes) + wires
  • 2 Green through hole LED's (1.6V-2V,2mA or less)
  • 2 Red through hole LED's (1.6V-2V,2mA or less)
  • 2 Yellow through hole LED's (1.6V-2V,2mA or less)
  • 6 470ohm 1/4W 5% resistors (1/2W or less, 10% or less)
  • 1 1Kohm 1/4W 5% resistor (1/2W or less, 10% or less)
  • 3 1.5Kohm 1/4W 5% resistors (1/2W or less, 10% or less)
  • 3 12Kohm 1/4W 5% resistors (1/2W or less, 10% or less)
  • 4 10Kohm 1/4W 5% resistors (1/2W or less, 10% or less)
  • 4 Push button switches (B3F tactile, breadboard-able)
  • 1 Mono or stereo headphone jack (breadboard compatible)
  • 1 Slide potentiometer (5-50K, breadboardable, 1-5cm slide)
